Vii®Fire iZone Fire Curtain – BS EN 1634-1

Key Information
  • Curtain Types: Fire Curtains
  • Product Standards: BS EN 1634-1, BS EN 1634-3
  • Standards: BS - British
  • Orientations: Vertical
  • Integrity Ratings: Up to 180 mins
  • Radiation Ratings: Up to 60 mins
  • Special Features: Tested to BS EN 1634-1. Classification: E180 EW60, Smoke Seals available for Smoke Control
fire icon Vertical icon 180 minutes fire rating

Quick Links
Sizes and Classification | Description | Downloads | Resources

Select your Product Standard:

BS 8524-1 BS EN 1634-1

Vertical - Single Roller 3m width x 3m drop (Maximum Size) E180 EW60 (E=Integrity, EW=Radiance)


the Vii®Fire i-Zone is Third Party Accredited and provideS smoke and fire control. Tested to BS EN 1634-1 with 180 minutes fire resistance.

Applications: Atrium, Lobbies and Receptions, Opening in Walls, Egress and Corridor Separations, Boundary Protection, Compartmentation, Stairs and Escalators, Lifts and Lift Lobbies, Protected Means of Escape

Developed to protect vertical applications, the ViiFire i-Zone can be installed into any standard building, including a domestic house, to protect lifts, kitchens, serving hatches and counters, windows and doors, openings in walls, stairs and lobbies, boundary protection and cross corridor separation.

ViiFire i-Zone can also be used to protect windows and form a protective means of escapes. Available in standard sizes up to 3m x 3m, ViiFire i-Zone can also be purchased as a supply only product and can be fixed to all types of ceiling configurations and is easily integrated with both solid and suspended ceilings.

ViiFire i-Zone is tested to BS EN 1634-1 and BS EN 1634-3 to provide Integrity and Radiation Control.

Minimum widths achievable are as follows:
Jumbo Bar – 900mm


BIM and NBS Source

nbs source logo


Coopers Fire can offer support with your BIM Project.
Find out more about Coopers Fire BIM capabilities and how we can help.

Specification Download
Certification Download
Brochure Download
Side Guides & Headbox - PDF Only Download
Side Guides & Headbox - Full Drawing Pack Download
Fabric Datasheet Download
Declaration of Performance - EN 16034 Download
